| Model | CC-01 |
| Functions and Applications | It mainly process insulating cardboard for transformers and motors, glass fiber boards, etc. |
| Main motor power | 0.75KW |
| Power supply voltage and frequency | 220V, 380V, 400V, 415V……, 50Hz, 60Hz…….Customized according to different countries and regions. |
| Main motor speed range | 0-1400r/min |
| Cutting liner speed | 5-25m/min |
| Maximum cutting diameter | D1000mm |
| Minimum cutting diameter | D90mm |
| Ellipticity of processed circles | ±0.8mm |
| Cutting thickness range | 0.5-3mm |
| Lifting distance of the upper pressure plate | ﹥20mm |
| Lifting distance of the upper cutting blade | ﹥25mm |
| Net weight | 500kg |
| External dimensions(L×W ×H) | 1300×500×800mm |
